DNM Air Shock Suspension

$99.00 SGD

DNM Air Shock Suspension

The DNM AOY-36RC XC/MTB/Trail/Cyclocross Bike Rear Shock has been fitted with a lockout and fully adjustable high-pressure system. This makes it ideal for all types of terrain.

Add to cart

Made from 6061-T6 a hard anodized alloy, make it very light whilst still retaining its strength and durability. Available in two base length eye to eye x travel options either 165mm x 35mm (6.50" x 1.38"), 190mm x 45mm (7.83" x 1.78"), 200mm x 51mm (7.87 x 2.01").

Watch the difference between a stock spring coil suspension vs an air shock absorber suspension:

Here is a side by side comparison of Spring suspension vs hydraulic shock suspension. Both are DNM shocks but see the difference between a spring suspension and a hydraulic shock below.



The air shock behaves similarly to hydraulic shocks with more damping but slower rebound.

Hydraulic/air shocks have lower resonance peak over bumps giving the rider less body stress. When resonance is high and stays high like on the spring suspension, the body absorbs that and over a period of time, the body will feel the stress.

In the video above, you observe the spring suspension rebounds very abruptly, this creates high resonance and stress on the rider.

User Manual: https://www.dnmshock.com/upload_files/products/18/ao-38rc.pdf

 REAR SHOCK Measurement as follows.

  • Eyelet diameter (B1&B2): 6 mm, 8 mm
  • Eyelet Width (C1&C2): 22-50mm
 Model
DNM AOY-36RC
DNM AO-42AR DNM DV 22
Weight
300g
280g 200g
Length
165mm x 35mm (6.50" x 1.38")
165mm x 38 mm (6.50" x 1.50")
135mm (eye to eye)
Eyelet diameter
8mm
8mm
10mm
Eyelet width
22mm~40mm
22mm~40mm
22mm~40mm
Damping
4-system
- Oil Damping with floating piston
Adjustments
Rebound / Lock out / Adjust High Pressure
Rebound/Air Pressure Adjustable
N/A
Damper shaft
Dark hard-anodized AL-7075 Ø 10 mm (0.39 inch) shaft;
Dark hard-anodized AL-6061 shock body
Dark hard chromed shock ∅10 mm ( 0.39 inch ) shaft;
Dark hard-anodized AL-6061 shock body
T6 forged AL6061 spring stopper, top eyelet and body.
Riding style

XC/Trail

XC/Trail

Not for XC/Trail, Urban bumps


[/
